SC UPC APC PC SM Single Mode 55mm Connector Fiber Optic Adapter Quick Connector

Name: SC UPC APC PC SM Single Mode 55mm Connector Fiber Optic Adapter Quick Connector
Brand: Fongko
Price: 1 USD

Wholesale SC UPC APC PC SM Single Mode 55mm Connector Fiber Optic Adapter Quick Connector from china suppliers

Brand Name : Fongko

Model Number : FKSU003-55

Certification : SGS

Place of Origin : Shenzhen

MOQ : 100 pcs

Price : Negotiatable

Payment Terms : T/T

Supply Ability : 10000 pcs per 1 day

Delivery Time : 3 days

Product name : SC/APC Connectors Fast Connector

Use : other, FTTH/Area Network/Test Equipment

Warranty Time : 1 YEAR

Fiber Mode : SM (singlemode), MM (multimode)

Fiber cable type : 0.9mm/2.0mm/3.0mm

Insertion Loss : Average value≤0.25 dB,max value≤0.3 dB

Endurance : 100times re-connections, ≤0.3dB

Fiber Diameter : 125um ( G652 ,G657 )

Contact Now

Ftth SC APC Connector Quick Connector SC Fast Connector

Fiber Optic Fast Connector also known as a field-installable connector or mechanical splice connector, is a device used to
connect optical fibers quickly and efficiently without the need for complex splicing equipment. These connectors provide a
reliable and cost-effective method to terminate fiber optic cables in the field.
Key Features:
* Ease of Installation: Designed for rapid field installation with minimal tools. The connector comes pre-polished, requiring only basic skills to terminate a fiber.
* Speed: Significantly reduces installation time compared to traditional fusion splicing, as it doesn’t require curing or epoxy.
* Reusability: Some models can be reused, allowing adjustments and reconnections.
* Low Loss: Provides acceptable insertion and return loss values for many applications, such as telecommunications, data networks, and FTTH (fiber-to-the-home) installations.
* Versatility: Available in different types to support various types of fibers (single-mode or multi-mode) and connector types (SC, LC, FC, ST).

country of origin	China
type	Quick Connectors
Keywords	Fiber Optic Quick Connector SC/UPC
Material	ABS
Model	FKSU003-55
Fiber Mode	SM (single mode), MM (multi mode)
Insertion loss	Average value ≤ 0.25 dB, maximum value ≤ 0.3 dB
Optical cable type	0.9mm/2.0mm/3.0mm
Operating temperature	-40℃ - 75℃
endurance	100 reconnections, ≤ 0.3dB
Operating temperature:	-40℃ - 75℃

SC UPC APC PC SM Single Mode 55mm Connector Fiber Optic Adapter Quick Connector
